| MOLDED SERIES BEAMS | ASSEMBLED SERIES BEAMS | |
|---|---|---|
| DETERMINE WHICH OF OUR FAUX WOOD CEILING BEAM TYPES IS BEST FOR YOUR PROJECT |  |  |
| PRICING | $ $ $ | $ $ $ $ |
| APPLICATION TYPE | Decorative - Non-Structural | Decorative - Non-Structural |
| MATERIAL TYPE | HDU (High Density Urethane) | HDU (High Density Urethane) |
| MANUFACTURING PROCESS | Cast in 1-Piece from a Mold | Custom Assembled w/ Mitered Corners |
| MANUFACTURING LEAD TIME | Ships in 2 Weeks | Ships in 4 Weeks |
| BEAM WALL THICKNESS | 3/4" to 1-1/4" | 1" |
| CONFIGURATION OPTIONS | 3-Sided | 2-Sided | 3-Sided | 4-Sided |
| SIZE OPTIONS | - 6"W x 4"H - 6"W x 6"H - 8"W x 6"H - 8"W x 8"H - 10"W x 8"H - 10"W x 10"H | Any Combination of: 4"W to 30"W x 4"H to 30"H In 1 Inch Increments |
| LENGTH OPTIONS | - 8ft - 10ft - 16ft - 20ft | 4ft to 50ft In 1 Foot Increments |
| TEXTURE OPTIONS | - Douglas Fir - Hand Hewn | - Douglas Fir - Hand Hewn - Rough Sawn - Sandblasted - Tuscany |
| FACTORY FINISH OPTIONS | - Primed - Pre-Finished Stain | - Primed - Pre-Finished Stain |
| STAIN COLOR OPTIONS | - Dark Walnut - Espresso - Gray - Light Walnut - Mahogany - Oak | - Dark Walnut - Espresso - Gray - Light Walnut - Mahogany - Oak |
| HOW TO FINISH PRIMED BEAMS | Paint or Stain as Desired | Paint or Stain as Desired |
| END CAP OPTIONS | - None | - Square - Angled - Chamfered - Corbel |
| FIRE RATED OPTIONS | NO | YES |
| PRICE & PURCHASE ONLINE | YES Shop Now! | YES Shop Now! |
| RESIDENTIAL & COMMERCIAL USE | YES | YES |
| NEW CONSTRUCTION & REMODEL USE | YES | YES |
| INTERIOR & EXTERIOR USE | YES | YES |
| INTERIOR DIMENSIONS | Slightly Irregular Call for Advise on Fitment When Using to Cover Objects | Precise To Calculate: Subtract 2" In Width and 1" in Height from Exterior Dimension |
| SKILL LEVEL & TOOLS NEEDED TO INSTALL | SKILL = Basic Carpentry TOOLS = Basic Carpentry | SKILL = Basic Carpentry TOOLS = Basic Carpentry |
| INSTALLATION METHOD | Wood Cleats w/ Construction Adhesive & Finish Nails and/or Screws | Wood Cleats w/ Construction Adhesive & Finish Nails and/or Screws |
| NUMBER OF PEOPLE NEEDED TO INSTALL | 2 Suggested | 2 Suggested |
| CUTTING REQUIRED TO INSTALL | YES - Beams are Trimmed to Length for Precise Fit | YES - Beams are Trimmed to Length for Precise Fit |
| CAN BE USED TO WRAP EXISTING STRUCTURAL BEAMS | YES | YES |
| CAN ROUTE WIRING OR PLUMBING INSIDE THE BEAMS | YES | YES |
| CAN INSTALL LIGHT FIXTURES IN THE BEAMS | YES - Additional Support Blocking Required | YES - Additional Support Blocking Required |
| CAN BE INSTALLED ON A VAULTED CEILING | YES | YES |
| CAN BE INSTALLED ON A CURVED CEILING | NO | YES - Custom Curved Beams Available |
| DECORATIVE HARDWARE AVAILABLE | YES Shop Now! | YES Shop Now! |
| MATCHING PLANKS AVAILABLE | YES Shop Now! | YES Shop Now! |
| BEAM WEIGHTS | 6”W x 4”H = 1.5 lbs per ft 6”W x 6”H = 1.8 lbs per ft 8”W x 6”H = 2 lbs per ft 8”W x 8”H = 2.4 lbs per ft 10”W x 8”H = 2.5 lbs per ft 10”W x 10”H = 3 lbs per ft | 1.4 lbs per sq ft of beam |
| SHIPMENT METHOD | LTL Freight | LTL Freight |
